The FLX-DANTE/SRC is a compact DANTE-to-anything converter with built-in 64x64ch Sample Rate Converter (SRC). It can convert 64x64ch of Dante to to any protocol installed into the AUX slot. For larger systems, the built-in channels plus everything which the AUX card provides are also available on the FlexLink port, making it possible to use it as extension to the MVR-mkII or another Flexiverter.

Specifications

• Two DANTE ports on Ethercon connectors
• AUX port accepting any of the AUX Cards as conversion source/destination
• When combined with AUX-DANTE, it acts as Dante/Dante bridge with full network and clock domain separation
• 64x64ch bi-directional Sample Rate Converter with top-notch specifications (>120dB THD N, >134dB DNR), can be bypassed when desired
• Supports sample rates from 44.1 to 192kHz
• FlexLink port for lowest latency, bi-directional transfer of 192 channels audio, clock and power
• Remote control via USB:  (no software required), or UART command line
• Triple-redundant power supply
