Fully Adheres to National Defense Authorization Act (NDAA) GuidelinesLightHunter illumination technology ensures ultra-high color image up to 0.003 Lux (F1.6)Exceptional Video Quality with 5MP, 2880 x 1620 ResolutionSuper-Efficient H.265 Video Compression for Drastically Reduced Bandwidth and Storage RequirementsPowerful, Smart IR LED Lights for 0Lux Night Time Operation up to 98 Feet2.8mm fixed lens, Triple Video Streams, ONVIF Profile S CompliantTRUE Day/Night and WDR functionality for all Lighting ConditionsOne-way Audio w/ built-in microphone, Corridor View, Backlight Compensation and 3D DNR(Digital Noise Reduction)Triple Video Streams, ONVIF Profile S Compliant; PoE & 12VDC Power OptionsIntelligent, smart intrusion prevention technology for significantly reduced false alarms when focusing on humans and motor vehiclesBuilt-in Micro-SD Card Slot enables local storage up to 256GBIP67 Weather Resistant Housing, Optional Wall and Pendant Mounts AvailableSupported by uniview tec Guard Station Software and Guard Viewer Mobile App’s for iPhone and Android Devices
| Camera | |
|---|---|
| Sensor | 1/2.7", progressive scan , 5 megapixel, CMOS |
| Lens | 22.8mm@ F1.6 |
| Angle of View (H x V ) | 96.1° x 55.3° |
| Shutter | Auto/Manual, 1 ~ 1/100000 s |
| Minimum Illumination | Color: 0.003 Lux (F1.6, AGC ON); 0 Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital noise reduction | 2D/3D DNR |
| IR LED Range | Up to 30m (98 ft) IR range |
| WDR | 120dB |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Maximum Frame Rate / Stream | Main Stream: 5MP (2880 x 1620) @ 30 fps; 4MP (2560 x 1440) @ 30 fps; 3MP (2304x 1296) @ 30 fps; 2MP (1920 x 1080) @ 30 fps Sub: 720P (1280 x 720) @ 30fps Third Stream: D1 (720 × 576) @ 30fps |
| HLC, BLC, Flip, 9:16 Corridor, Defog | Supported |
| OSD, Privacy Mask, Motion Detection & ROI | Up to 8 areas |
| Network | |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, SNMP |
| Compatible Integration | ONVIF (Profile S, Profile T), API |
| Network | RJ45, 10M/100M Base-TX Ethernet |
| Intelligent Perimeter Protection | Cross Line, Intrusion, Enter Area, Leave Area detection; Motion detection |
| General | |
| Power | 12VDC /- 25%, PoE (IEEE802.3 af); Max 4W |
| Dimensions (Ø x H) & Weight | ?110.5 x 94.1mm (Ø4.4 x 3.7”); 0.425kg (0.93lb) |
| Audio I/O & Compression | 1 / 0, w/ built-in microphone; G.711 |
| Operating Temperature & Humidity |
-30°C ~ 60°C (-22°F ~ 140°F); Humidity: 10%~ 95% RH (non-condensing) |
| Conformity Certifications | IP67, CE, FCC |
